VigilLink 1x2 HDMI 2.1 Distribution Amplifier 48 Gbps with audio de-embeder / VLSP-12H21SA

This 8K HDMI 1x2 Splitter can distribute one HDMI source signal to any two display devices. Video resolution is up to 8K@60Hz 4:2:0 12bit. It supports data rates up to 48Gbps to comply with HDMI 2.1 and HDCP 2.3 requirements. It also has advanced EDID management and audio de-embedding function (output through the optical and analog port). This multi-functional product can work well with xbox or PS5 to achieve 4K@120Hz video resolution on your TVs or relative monitors.

Featured Highlights

• HDMI 2.1 and HDCP 2.3 compliant

• Support 48Gbps FRL and 18Gbps TMDS video bandwidth

• Support resolution up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit

• VRR, FVA, ALLM supported

• Support HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through

• Support HDMI audio formats: LPCM 7.1CH, Dolby TrueHD, Atmos, DTS-HD Master Audio

• Support audio de-embedding function (output through the optical and analog port)

• Support resolution auto downscaling and converting on each output port

• Advanced EDID management

Specifications
