Vigillink, 1G JPEG2000 4K60 4:4:4 AVoIP Receiver w/Videowall Processing, KVM, IR, RS-232, VLIP-JP4K6K-DC

This product is based on JPEG2000 technology. It integrates the Copper port and Fiber port within a single box. Encoder input supports up to 4K60 4:4:4, audio embedding, or extracting. Decoder output supports up to 4K60 4:4:4 audio extracting. The product supports ARC/eARC/SPDIF/Analog audio return function, USB2.0/KVM/Camera, 1G Ethernet, bidirectional RS- 232, two-way IR, and PO function. Guest mode controls of RS-232, IR, and CEC are supported. Built-in two two-channel ports and two-channel I/O ports for contact control.

Built-in MJPEG Substream, which supports plenty of API commands to achieve flexible configurations, is helpful party control Apps to preview video content.

The system is based on Linux for software development and provides flexible control methods based on the intelligent networking of a 1G Ethernet Switch.

Featured Highlights

• HDMI 2.0b, HDCP 2.2 compliant

• Support 18Gbps video bandwidth

• Input and output video resolution is up to 4K60 4:4:4

• Signal transmission distance can be extended up to 328ft / 100m via CAT5E/6/6A/7 cable

• Transmit video, analog/digital audio, IR , RS-232, CEC and USB over Ethernet

• Integrate Copper port and Fiber port within a single box

• ARC/eARC/SPDIF/Analog audio return function

• Channel configuration via front panel buttons and LED screen

• Built-in two channel RELAY ports and two channel I/O ports for contact control

• Support unicast and multicast functions

• Support point-to-point, video matrix and video wall functions (video wall supports up to 9x9)

• Intelligent video wall class management

• Support MJPEG Substream real-time preview

• 1G Ethernet Switch

• Support POE function

• Built-in web page configuration and control, Telnet and SSH as well

• HDMI audio formats: LPCM 2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby

• True HD, DTS, DTS-96/24, DTS-EX DSD, DTS High Res, DTS-HD Master

• Smart networking design for easy and flexible installation

Specifications
