IR Receiver

$23.95
SKU SW-32830
Type

Related Products:
See Also:

Clean home theater set-ups (especially set-ups with wall-mounted HDTVs) can require you to store your video equipment (like Blu-Ray players, DVD players, TIVOs, etc.) in a remote place like a closet or another room. Since your remote controls require line-of-sight to control your equipment, you won't be able to use them unless you can send the remote signal which is an infrared (or IR) signal to your equipment with a wired extender.

This IR Receiver is used in tandem with any combination of different IR Emitters and connecting blocks. The receiver is mounted on or near your TV However in most cases you will need them in addition to a IR Receiver. If you're looking to expand your already existing setup then this is what you're looking for. If you're starting from square one, check out our IR Receiver Kits.

Compatibility

Please note that IR Receivers are not universally compatible with all devices. Please consult the list below to check which of our products the IR Receiver is compatible with.

  • Fisheye: BlastIR Pro and Pro Multizone
  • Classic: BlastIR Classic and Wireless
  • Pro: BlastIR Pro and Pro Multizone
  • Keystone: BlastIR Classic and Wireless
  • Wall Plate: BlastIR Classic and Wireless

Specifications

Compatibility

Please note that IR Receivers are not universally compatible with all devices. Please consult the list below to check which of our products the IR Receiver is compatible with.

  • Fisheye: BlastIR Pro and Pro Multizone
  • Classic: BlastIR Classic and Wireless
  • Pro: BlastIR Pro and Pro Multizone
  • Keystone: BlastIR Classic and Wireless
  • Wall Plate: BlastIR Classic and Wireless

Fisheye

  • Designed to be inserted into a pre-drilled hole in a wall or cabinet
  • Works with all brands of Audio/Video IR remote controls
  • IR receiving distance: 18' - 30' (remote control dependent)
  • Receiving frequencies: 34 - 60 kHz
  • Dimensions: 50mm tube length, 11.75mm tube diameter, 15.7 head diameter
  • 4.5ft cable

Classic

  • Designed to be surface mounted in multiple applications.
  • Work with practically all brands of Audio/Video IR remote controls
  • IR receiving: 18'~ 30'(remote control dependent)
  • Operating Frequency: 38 & 56KHz
  • Dimension: 45mm x 15mm x 12mm (receiver)

Pro

  • Designed to be surface mounted in multiple applications.
  • Works with all brands of Audio/Video IR remote controls
  • IR receiving: 18' ~ 30' (remote control dependent)
  • Receiving frequencies: 34 - 60 kHz
  • Dimension: 20mm x 15mm x 13mm (receiver only)
  • Includes adhesive tape for IR mounting
  • 4 feet cable
  • Tip - IR Signal
  • Ring - 5V
  • Sleeve - Gnd

Keystone

  • Receiver Frequency Range: 34 KHz to 60 KHz
  • Transmit Frequency Range: 38 KHz to 56 KHz
  • Range: 40ft @ 38 KHz, 25ft @ 56 KHz
  • Power: DC 12V, 30 mA max
  • Dimensions: 39.2L x 19.3W x 24.3H mm

Wall Plate

  • Designed to be surface mounted in multiple applications.
  • Works with practically all brands of Audio/Video IR remote controls
  • IR receiving: 18'~ 30'(remote control dependent)
  • Operation Frequency: 38 & 56KHz
  • Dimension: 114mm x 70mm x 18mm
  • Power supply: 12VDC, 200mA

Videos

Troubleshooting

Customer Reviews

Based on 9 reviews
44%
(4)
22%
(2)
22%
(2)
0%
(0)
11%
(1)
p
p.
Part Number: SW-30458-R
Miss leading info given

Pros: Cons: Info on this device says "Works with all brands of Audio/Video IR remote controls". This is very misleading! Several AV receivers have a 3.5 mm Remote in jack in the back of the unit. They require a voltage of at least 5 V and a couple mA current (>50mW) to drive a LED. This device does not do that!Other: I could recommend a unit to work with such AV recievers, but that probably wouldn't be right.

Sorry if the information on our site was misleading. This receives infrared signals in the 34-64 kHz IR band, which virtually all remotes on the market use. It can only be plugged into our SW-30458 BlastIR Pro though.
A
A.
Part Number: SW-30458-R
Didn't work

Pros: Cons: plugged in out of box, and receiver was dead, no light or IR responseOther: Unit was dead on arrival. Tried several ports on BlastIR, but no response. Please send a replacement.

No problem, I'll set you up with an RMA right away. This order was for the receiver only but I don't see a previous order where you ordered the BlastIR Pro that this works with. What was your order number for that? This extra receiver won't work without that kit.
A
A.
Part Number: SW-30458-R
Blast IR Pro

Pros: The Blast IR Pro is pretty straight forward and works well when only using one input. Can have several IR outputs without problem. Cons: The unit has 3 IR inputs but my experience after working with 3 separate Blast IR pros is that the u it will only transfer the input signal to the IR outputs if there is one one IR input plugged in. I tried several times having more than 1 input plugged and and all three units failed to work when I had more than one IR input plugged in (and yes I tried several combinations of inputs - 1 and 2, 2 and 3, 1 and 3, 2 and 3....no two inputs could be plugged in at the same time)Other:

D
D.
Part Number: SW-30458-R
Works great

Pros: Item came promptly and works great. Cons: Other:

R
R.
Part Number: SW-29315
Dual Band In-Wall IR Receiver

Pros: Easy to install and works very wellCons: None so farOther:
